Guide To Tilt and Turn Windows

1. Versatile Opening Mechanism

• The tilt mode allows for controlled ventilation without fully opening the window.

• The turn mode provides a full opening for easy access and maximum airflow.


2. Superior Security

• Multi-point locking system makes them harder to break into.

• Tilt function allows for ventilation while keeping the bottom of the window securely closed.

• Toughened or laminated glass offers extra protection.


3. Energy Efficiency

• Tilt and turn double glazed windows provide excellent insulation, reducing energy loss.

• Keeps your home warmer in winter and cooler in summer, lowering heating and cooling costs.


4. Easy Maintenance

• Since the window opens inward, it can be cleaned from inside the home—ideal for high-rise apartments.

• No need to reach outside or hire professional window cleaners for upper floors.


5. Modern Aesthetic

• Sleek and contemporary design, especially aluminium tilt and turn windows, which offer a minimalist, high-end look.

• Available in various frame materials, including uPVC, timber, and aluminum.


6. Improved Sound Insulation

• Tilt and turn double glazed windows reduce external noise, making them ideal for busy city environments.


7. Child Safety and Pet-Friendly Design

• The tilt function allows fresh air in without creating an opening large enough for children or pets to climb through.


1. Higher Cost

• More expensive than traditional casement or sliding windows due to the advanced dual-function mechanism.

• Aluminium tilt and turn windows cost more than uPVC but offer better durability.


2. Heavier and Bulkier

• The sturdy construction makes them heavier than standard windows, requiring strong wall support.

• Larger turn and tilt windows may need reinforced hinges to support the weight.


3. Cannot Open Outwards

• Unlike casement or sliding windows, turn and tilt windows only open inward, which may not suit every home’s layout.

Security is a top priority for homeowners, and turn and tilt windows offer great security features available. Here’s some:

• Multi-Point Locking System – Features multiple locking points, ensuring security even when in tilt mode for ventilation.
• Reinforced Frames – High quality aluminium tilt and turn windows offer additional strength and resistance to break ins.
• Toughened or Laminated Glass – Tilt and turn double glazed windows come with reinforced glass, increasing security and impact resistance thus making it harder to break in.

If security is a priority, turn and tilt windows can be a much safer option than traditional casement or sliding windows.

Adjusting your Idealcombi tilt and turn windows ensures they operate smoothly and maintain optimal performance. Here’s how to make common adjustments:

1. Height Adjustment: To raise or lower the window sash:

• Locate the height adjustment screw on the bottom hinge.
• Use an Allen key to turn the screw:
  • Clockwise to raise the sash.
  • Counterclockwise to lower the sash. This ensures the sash aligns correctly within the frame.

2. Lateral Adjustment (Side Alignment): If the sash is misaligned horizontally:

• Find the lateral adjustment screws on both the top scissor hinge and the bottom hinge.
• Adjust these screws to move the sash left or right, ensuring it sits evenly within the frame.

3. Adjusting Closing Pressure: To modify the pressure between the sash and the frame:

• Identify the mushroom bolts (locking pins) along the sash.
• Rotate these bolts:
  • Clockwise to increase pressure (tightening the seal).
  • Counterclockwise to decrease pressure. Proper adjustment ensures a firm seal, enhancing insulation and security.

4. Handle Operated Brake Adjustment: If your window features a handle-operated brake to hold the sash in position when opened:

• Open the window to the desired position (between 19° and 89°).
• Turn the handle downward to activate the brake, securing the sash in place.
• To release, slightly open the sash further, then return the handle to its original position. This mechanism allows the window to stay open at various angles for controlled ventilation.

5. Resetting the Espagnolette (Locking Mechanism): If the locking mechanism becomes misaligned:

• Position the handle horizontally.
• Gently push the sash into the frame.
• Turn the handle upward to the vertical position.
• Close the window by turning the handle downward to the locked position. This sequence resets the espagnolette to its default state.

Important Considerations:

• Always perform adjustments with the window closed to ensure safety and accuracy.
• Use appropriate tools, typically an Allen key, for these adjustments.
• Regularly inspect and maintain your windows to prolong their lifespan and functionality.

For detailed guidance and visual aids, refer to Idealcombi’s official user manuals.

Turn and tilt windows offer a perfect blend of versatility, security, and energy efficiency, making them an excellent choice for modern homes and buildings. Their unique dual function design allows for controlled ventilation while maintaining security.

If you’re looking for windows that offer security, energy efficiency, and ease of use, then IdealCombi tilt and turn windows are an excellent choice. Whether you opt for aluminium turn and tilt windows for their longer durability or tilt and turn double glazed windows for better insulation, these windows provide superior performance compared to traditional designs.
