Technical overview

High Performance Specifications

Solar neutral HP 70-35 - 6mm toughened, argon, 6mm toughened, argon, 6mm toughened

Low-E 14mm warm edge spacer
Ug-Value: 0.6 W/(m²K)
Light Transmission: 62
Solar Factor (g): 31

Solar neutral HP 70-35 - 6mm toughened, argon, 6mm toughened, argon, 6.4mm laminated
Required for Part Q compliance

Low-E 14mm warm edge spacer
Ug-Value: 0.6 W/(m²K)
Light Transmission: 62
Solar Factor (g): 31

Standard Specifications

Low-E - 6mm toughened, argon, 6mm toughened, argon, 6mm toughened

Low-E 14mm warm edge spacer
Ug-Value: 0.7 W/(m²K)
Light Transmission: 62
Solar Factor (g): 42

Low-E - 6mm toughened, argon, 6mm toughened, argon, 6.4mm laminated
Required for Part Q compliance

Low-E 14mm warm edge spacer
Ug-Value: 0.7 W/(m²K)
Light Transmission: 62
Solar Factor (g): 42

High Performance Specifications

Solar neutral HP 70-35 - 6mm toughened, argon, 6mm toughened

24mm warm edge spacer
Ug-Value: 1.1 W/(m²K)
Light Transmission: 70
Solar Factor (g): 38

Solar neutral HP 70-35 - 8mm toughened, argon, 8mm toughened
Required for panels above 6m²

22mm warm edge spacer
Ug-Value: 1.0 W/(m²K)
Light Transmission: 69
Solar Factor (g): 38

Solar neutral HP 70-35 - 6mm toughened, argon, 8.8mm clear laminate
Required for Part Q compliance

22mm warm edge spacer
Ug-Value: 1.0 W/(m²K)
Light Transmission: 69
Solar Factor (g): 38

Solar neutral HP 70-35 - 8mm toughened, 10.8mm clear laminate
Required for Part Q compliance

18mm warm edge spacer
Ug-Value: 1.0 W/(m²K)
Light Transmission: 69
Solar Factor (g): 38

Standard Specifications

Low-E - 6mm toughened, argon, 6mm toughened

24mm warm edge spacer
Ug-Value: 1.2 W/(m²K)
Light Transmission: 79
Solar Factor (g): 66

Low-E - 8mm toughened, argon, 8mm toughened
Required for panels above 6m²

20mm warm edge spacer
Ug-Value: 1.2 W/(m²K)
Light Transmission: 79
Solar Factor (g): 64

Low-E - 6mm toughened, argon, 8.8mm clear laminate
Required for Part Q compliance

22mm warm edge spacer
Ug-Value: 1.2 W/(m²K)
Light Transmission: 76
Solar Factor (g): 60

Low-E - 8mm toughened, argon, 10.8mm clear laminate
Required for Part Q compliance

18mm warm edge spacer
Ug-Value: 1.2 W/(m²K)
Light Transmission: 74
Solar Factor (g): 58

PureView

Single track

1 Fixed panel – style 411

2 fixed panels – style 413SR

Double track

2 panels with fixed on the left – style 421

2 panels sliding right and left – style 423

2 panels with fixed on the right – style 422

4 panels sliding to the center and to the sides – style 427

4 panels with fixed on the right and left – style 426

Tripple track

3 panels with fixed on the right – style 432

3 panels with fixed on the left – style 431

3 panels sliding left and right – style 433

6 panels with fixed on the right and left – style 435

Quad track

4 panels with fixed on the right – style 441

4 panels with fixed on the left – style 441

8 panels with fixed on the right and left – style 445

Glass to glass corner

2 fixed panels joined with 3 panels with fixed on the left – style 412SR x 431

Open corner

3 panels with fixed on the left joined with 3 panels with fixed on the right – style 432 x 431

2 panels with fixed on the left joined with 3 panels with fixed on the right – style 421 x 431

2 panels with fixed on the left joined with 2 panels with fixed on the right – style 421 x 422
